M35-HSS Flat End Mills-Metric
Description
- These HSS End Mills are manufactured in AISI M35 - 5% coblat grade in metric sizes
- These HSS Cutting Tools comes with hardness of 63~66HRc
- HSS End Mills are best suited for milling general materials on MLTR machines at higher parameters than M2 End Mills
- These End Mills come in 4 or 6 flutes with non-center cutting type
- HSS End Mills are also manufactured in M42 8% Cobalt grade on request
Item List
| Item | Flute Dia (mm) | Flute Length (mm) | Shank Dia (mm) | Overall Length (mm) | ||
|---|---|---|---|---|---|---|
| HR2XGSE00EA1 | 3 | 10 | 4 | 42 |
|
|
| HR2XGSE00ED4 | 4 | 11 | 4 | 43 |
|
|
| HR2XGSE00EF0 | 5 | 13 | 5 | 47 |
|
|
| HR2XGSE00EH6 | 6 | 16 | 6 | 52 |
|
|
| HR2XGSE00EK9 | 7 | 16 | 8 | 52 |
|
|
| HR2XGSE00EM5 | 8 | 19 | 8 | 59 |
|
|
| HR2XGSE00EN2 | 9 | 19 | 10 | 59 |
|
|
| HR2XGSE00EQ6 | 10 | 22 | 10 | 67 |
|
|
| HR2XGSE00ER4 | 11 | 22 | 12 | 67 |
|
|
| HR2XGSE00ET9 | 12 | 26 | 12 | 76 |
|
|
| HR2XGSE00EV5 | 13 | 26 | 12 | 76 |
|
|
| HR2XGSE00EW3 | 14 | 26 | 12 | 76 |
|
|
| HR2XGSE00EY8 | 15 | 32 | 12 | 88 |
|
|
| HR2XGSE00F07 | 16 | 32 | 16 | 88 |
|
|
| HR2XGSE00F15 | 17 | 32 | 16 | 88 |
|
|
| HR2XGSE00F31 | 18 | 32 | 16 | 88 |
|
|
| HR2XGSE00F49 | 19 | 38 | 16 | 101 |
|
|
| HR2XGSE00F64 | 20 | 38 | 20 | 101 |
|
|
| HR2XGSE00F98 | 22 | 38 | 20 | 101 |
|
|
| HR2XGSE00FD3 | 25 | 45 | 25 | 116 |
|
