205-4-Flute TX Solid Carbide Flat End Mills upto 55HRc Machining-Metric

Description
  • Most Economical Carbide End Mill series developed for Die-Mold Application at RIGPL
  • Best in its range in the market for Die-Mold & other general milling applications
  • 4-Flute Carbide End Mills comes with Hyperlox Coating
  • Good for milling die steel, tool steel & other hardened materials up to 55-HRc

Item List

Item Flute Dia (mm) Flute Length (mm) Shank Dia (mm) Overall Length (mm)
CR16GSE00HX4 2 6 4 50

CR16GSE00HY2 2.5 8 4 50

CR16GSE00HZ0 3 12 3 50

CR16GSE00J00 3 20 3 75

CR16GSE00J18 3 25 3 100

CR16GSE00J26 4 14 4 50

CR16GSE00J34 4 20 4 75

CR16GSE00J42 4 25 4 100

CR16GSE00J59 5 16 5 50

CR16GSE00J67 5 20 5 75

CR16GSE00J75 5 25 5 100

CR16GSE00J83 6 16 6 50

CR16GSE00J91 6 25 6 75

CR16GSE00JA3 6 30 6 100

CR16GSE00JB1 6 50 6 150

CR16GSE00JC9 8 20 8 60

CR16GSE00JD6 8 30 8 100

CR16GSE00JE4 8 50 8 150

CR16GSE00JF2 10 25 10 75

CR16GSE00JG0 10 40 10 100

CR16GSE00JH8 10 50 10 150

CR16GSE00JJ3 12 25 12 75

CR16GSE00JK1 12 40 12 100

CR16GSE00JL9 12 50 12 150

CR16GSE00JM7 16 40 16 100

CR16GSE00JN4 16 50 16 150

CR16GSE00JP0 20 40 20 100

CR16GSE00N14 1 3 4 50

CR16GSE00N22 1.5 4 4 50
