201-4-Flute 1X Solid Carbide Flat End Mills-Metric

Description
  • 4-Flute General Purpose Carbide End Mills with TiALN coating,
  • Better performing End Mills then our 101, 103 series
  • Good for milling metals like MS, CI, GCI, Steels up to 45-HRc

Item List

Item Flute Dia (mm) Flute Length (mm) Shank Dia (mm) Overall Length (mm)
CR11GSE00332 14 30 14 75

CR11GSE009A5 3 15 3 50

CR11GSE009B3 3 20 3 75

CR11GSE009C1 3 25 3 100

CR11GSE009E6 4 14 4 50

CR11GSE009G2 4 20 4 75

CR11GSE009H0 4 25 4 100

CR11GSE009J5 5 16 5 50

CR11GSE009K3 5 20 5 75

CR11GSE009L1 5 25 5 100

CR11GSE009Q0 6 16 6 50

CR11GSE009R8 6 25 6 75

CR11GSE009S5 6 30 6 100

CR11GSE009T3 6 50 6 150

CR11GSE009X4 7 20 7 60

CR11GSE00A04 8 20 8 60

CR11GSE00A12 8 25 8 75

CR11GSE00A20 8 30 8 100

CR11GSE00A38 8 50 8 150

CR11GSE00A46 9 25 9 75

CR11GSE00A79 10 25 10 75

CR11GSE00A87 10 40 10 100

CR11GSE00A95 10 60 10 150

CR11GSE00AA7 12 25 12 75

CR11GSE00AB5 12 40 12 100

CR11GSE00AC3 12 60 12 150

CR11GSE00AD0 12 60 12 200

CR11GSE00AF6 14 40 14 100

CR11GSE00AG4 14 60 14 150

CR11GSE00AH2 14 60 14 200

CR11GSE00AJ7 16 40 16 100

CR11GSE00AK5 16 60 16 150

CR11GSE00AL3 16 60 16 200

CR11GSE00AM1 18 40 18 100

CR11GSE00AN8 18 60 18 150

CR11GSE00AP4 18 60 18 200

CR11GSE00AQ2 20 40 20 100

CR11GSE00AR0 20 60 20 150

CR11GSE00AS7 20 60 20 200

CR11GSE00AT5 25 40 25 100

CR11GSE00AU3 25 60 25 150

CR11GSE00AV1 25 60 25 200

CR11GSE00HB8 11 25 11 75

CR11GSE00HC6 13 40 13 100

CR11GSE00HW2 16 30 16 75

CR11GSE00PJ2 8 50 8 200

CR11GSE00PK0 22 40 22 100

CR11GSE00PL8 10 60 10 200

CR11GSE00SR2 13 25 13 75
