C3HL-Steel-High Performance Solid Carbide Drills-Long-Metric

Description

These Carbide Drill Bits have new chip curling design to enable chip breakage,
3~4 Times production compared to General Carbide Drill Bits like C1GS, C1GJ series
These Carbide Cutting Tools are best suited for drilling MS, Alloy Steel, Cast Iron up to 450BHN, SS
Carbide Drill bits comes with Edge Chamfer and better edge preparation for longer drill life,
These Carbide Cutting Tools Comes with newly developed "NOVA" coating.

Item List

Item	Flute Dia (mm)	Flute Length (mm)	Shank Dia (mm)	Overall Length (mm)
CR3AHDR00FH2	2	21	4	57
CR3AHDR00FJ7	2.1	21	4	57
CR3AHDR00FK5	2.2	21	4	57
CR3AHDR00FL3	2.3	21	4	57
CR3AHDR00FM1	2.4	21	4	57
CR3AHDR00FN8	2.5	21	4	57
CR3AHDR00FP4	2.6	21	4	57
CR3AHDR00FQ2	2.7	21	4	57
CR3AHDR00FR0	2.8	21	4	57
CR3AHDR00FS7	2.9	21	4	57
CR3AHDR00FT5	3	28	6	62
CR3AHDR00FU3	3.1	28	6	62
CR3AHDR00FV1	3.2	28	6	62
CR3AHDR00FW9	3.3	28	6	62
CR3AHDR00FX6	3.4	28	6	62
CR3AHDR00FY4	3.5	28	6	62
CR3AHDR00FZ2	3.6	28	6	62
CR3AHDR00G03	3.7	28	6	62
CR3AHDR00G11	3.8	36	6	75
CR3AHDR00G29	3.9	36	6	75
CR3AHDR00G37	4	36	6	75
CR3AHDR00G45	4.1	36	6	75
CR3AHDR00G52	4.2	36	6	75
CR3AHDR00G60	4.3	36	6	75
CR3AHDR00G78	4.4	36	6	75
CR3AHDR00G86	4.5	36	6	75
CR3AHDR00G94	4.6	36	6	75
CR3AHDR00GA6	4.7	36	6	75
CR3AHDR00GB4	4.8	42	6	80
CR3AHDR00GC2	4.9	42	6	80
CR3AHDR00GD9	5	42	6	80
CR3AHDR00GE7	5.1	42	6	80
CR3AHDR00GF5	5.2	42	6	80
CR3AHDR00GG3	5.3	42	6	80
CR3AHDR00GH1	5.4	42	6	80
CR3AHDR00GJ6	5.5	42	6	80
CR3AHDR00GK4	5.6	42	6	80
CR3AHDR00GL2	5.7	42	6	80
CR3AHDR00GM0	5.8	42	6	80
CR3AHDR00GN7	5.9	42	6	80
CR3AHDR00GP3	6	42	6	80
CR3AHDR00GQ1	6.1	55	8	100
CR3AHDR00GR9	6.2	55	8	100
CR3AHDR00GS6	6.3	55	8	100
CR3AHDR00GT4	6.4	55	8	100
CR3AHDR00GU2	6.5	55	8	100
CR3AHDR00GV0	6.6	55	8	100
CR3AHDR00GW8	6.7	55	8	100
CR3AHDR00GX5	6.8	55	8	100
CR3AHDR00GY3	6.9	55	8	100
CR3AHDR00GZ1	7	55	8	100
CR3AHDR00H02	7.1	60	8	105
CR3AHDR00H10	7.2	60	8	105
CR3AHDR00H28	7.3	60	8	105
CR3AHDR00H36	7.4	60	8	105
CR3AHDR00H44	7.5	60	8	105
CR3AHDR00H51	7.6	60	8	105
CR3AHDR00H69	7.7	60	8	105
CR3AHDR00H77	7.8	60	8	105
CR3AHDR00H85	7.9	60	8	105
CR3AHDR00H93	8	60	8	105
CR3AHDR00HA5	8.1	75	10	125
CR3AHDR00HB3	8.2	75	10	125
CR3AHDR00HC1	8.3	75	10	125
CR3AHDR00HD8	8.4	75	10	125
CR3AHDR00HE6	8.5	75	10	125
CR3AHDR00HF4	8.6	75	10	125
CR3AHDR00HG2	8.7	75	10	125
CR3AHDR00HH0	8.8	75	10	125
CR3AHDR00HJ5	8.9	75	10	125
CR3AHDR00HK3	9	75	10	125
CR3AHDR00HL1	9.1	75	10	125
CR3AHDR00HM9	9.2	75	10	125
CR3AHDR00HN6	9.3	75	10	125
CR3AHDR00HP2	9.4	75	10	125
CR3AHDR00HQ0	9.5	75	10	125
CR3AHDR00HR8	9.6	75	10	125
CR3AHDR00HS5	9.7	75	10	125
CR3AHDR00HT3	9.8	75	10	125
CR3AHDR00HU1	9.9	75	10	125
CR3AHDR00HV9	10	75	10	125
CR3AHDR00HW7	10.1	85	12	140
CR3AHDR00HX4	10.2	85	12	140
CR3AHDR00HY2	10.3	85	12	140
CR3AHDR00HZ0	10.4	85	12	140
CR3AHDR00J00	10.5	85	12	140
CR3AHDR00J18	10.6	85	12	140
CR3AHDR00J26	10.7	85	12	140
CR3AHDR00J34	10.8	85	12	140
CR3AHDR00J42	10.9	85	12	140
CR3AHDR00J59	11	85	12	140
CR3AHDR00J67	11.1	85	12	140
CR3AHDR00J75	11.2	85	12	140
CR3AHDR00J83	11.3	85	12	140
CR3AHDR00J91	11.4	85	12	140
CR3AHDR00JA3	11.5	85	12	140
CR3AHDR00JB1	11.6	85	12	140
CR3AHDR00JC9	11.7	85	12	140
CR3AHDR00JD6	11.8	85	12	140
CR3AHDR00JE4	11.9	85	12	140
CR3AHDR00JF2	12	85	12	140
CR3AHDR00JG0	12.5	85	14	140
CR3AHDR00JH8	13	85	14	140
CR3AHDR00JJ3	13.5	85	14	140
CR3AHDR00JK1	14	85	14	140
CR3AHDR00JL9	14.5	90	16	145
CR3AHDR00JM7	15	90	16	145
CR3AHDR00JN4	15.5	90	16	145
CR3AHDR00JP0	16	90	16	145
CR3AHDR00JQ8	16.5	95	18	150
CR3AHDR00JR6	17	95	18	150
CR3AHDR00JS3	17.5	95	18	150
CR3AHDR00JT1	18	95	18	150
CR3AHDR00JU9	18.5	98	20	150
CR3AHDR00JV7	19	98	20	150
CR3AHDR00JW5	19.5	98	20	150
CR3AHDR00JX2	20	98	20	150
CR3AHDR00TR6	12.7	85	14	140
CR3AHDR00UB0	1.5	15	3	54
CR3AHDR00UC8	1.6	15	3	54
CR3AHDR00UD5	1.7	15	3	54
CR3AHDR00UE3	1.8	18	3	54
CR3AHDR00UF1	1.9	18	3	54
