CCA-Solid Carbide Center Drill Type A-Metric

Description
  • Carbide Center Drill Bits are used for General Centering process for wide range of materials
  • These Carbide Center Drill Bits have Better Life & productivity in comparison to HSS Co drill bits,
  • These Carbide Center Drill Bits are manufactured in Type A in both BSW & Metric sizes
  • These Carbide Center Drill Bits are manufactured with TiALN or FUTURA or TIN or other Harder coating(s) on request
  • These Carbide Center Drill bits are Good for large batch production.

Item List

Item Pilot Dia (mm) Pilot Length (mm) Body Dia (mm) Overall Length (mm)
CR1XCA00028 2 2.8 5 40

CR1XCA00044 2.5 3.5 6.3 45

CR1XCA00051 3.15 4.5 8 50

CR1XCA001J4 4 5.6 10 56

CR1XCA001L0 1.6 2.5 4 35

CR1XCA001M8 5 6.8 12.5 63

CR1XCA001N5 6.3 8.5 16 72
