304-2-Flute-HP-Solid Carbide Ball Nose-Metric

High performance carbide ball nose end mills for die-mold 3D profiling at higher cutting parameters
Solid carbide ball nose for milling hardened die steel and tool steel up to 60 HRc — D2, D3, H13, P20 and equivalents
2-flute ball nose design delivers higher finish and ease of regrinding for the tool room.
Outperforms the Closed 206 Series (TX Series) carbide ball nose end mills in both productivity and tool life
Precision-ground ball form maintains R-accuracy across the full 180° for accurate 3D contouring and copy milling
Finished with the newly developed NOVA coating for wear resistance and thermal stability at elevated cutting speeds

Item	Flute Dia (mm)	Flute Length (mm)	Shank Dia (mm)	Overall Length (mm)
CR33HBE00315	4	14	4	50
CR33HBE00323	6	25	6	75
CR33HBE00331	6	30	6	100
CR33HBE00349	8	50	8	150
CR33HBE00356	10	25	10	75
CR33HBE008R8	1	3	4	50
CR33HBE009M8	10	60	10	150
CR33HBE009N5	12	25	12	75
CR33HBE009Q9	12	60	12	150
CR33HBE00AT4	3	20	3	75
CR33HBE00AU2	4	20	4	75
CR33HBE00B51	3	25	3	100
CR33HBE00B69	4	25	4	100
CR33HBE00B77	10	40	10	100
CR33HBE00B85	8	30	8	100
CR33HBE00B93	6	16	6	50
CR33HBE00BA5	8	20	8	60
CR33HBE00BH0	8	25	8	75
CR33HBE00BP2	12	40	12	100
CR33HBE00BR8	3	15	3	50
CR33HBE00BX4	6	50	6	150
CR33HBE00C43	5	20	5	75
CR33HBE00E09	5	16	5	50
CR3AHBE00E39	1.5	3	4	50
CR3AHBE00E47	2	4	4	50
CR3AHBE00E54	2.5	5	4	50
