206-2-Flute TX Solid Carbide Ball Nose upto 55HRc Machining-Metric
Description
- Economical Carbide Ball Nose End Mills series developed for Die-Mold Application at RIGPL.
- Best in its range in the market for Die-Mold & other general milling applications.
- 2-Flute Carbide Ball Nose End Mills comes with Hyperlox Coating.
- Solid Carbide Ball Noses good for milling 55-HRc hardened die steel & tool steel.
Item List
| Item | Flute Dia (mm) | Flute Length (mm) | Shank Dia (mm) | Overall Length (mm) | ||
|---|---|---|---|---|---|---|
| CR16GBE00CJ7 | 1 | 3 | 4 | 50 |
|
|
| CR16GBE00CK5 | 1.5 | 4 | 4 | 50 |
|
|
| CR16GBE00CL3 | 2 | 6 | 4 | 50 |
|
|
| CR16GBE00CM1 | 2.5 | 8 | 4 | 50 |
|
|
| CR16GBE00CN8 | 3 | 12 | 3 | 50 |
|
|
| CR16GBE00CP4 | 3 | 20 | 3 | 75 |
|
|
| CR16GBE00CQ2 | 3 | 25 | 3 | 100 |
|
|
| CR16GBE00CR0 | 4 | 16 | 4 | 50 |
|
|
| CR16GBE00CS7 | 4 | 20 | 4 | 75 |
|
|
| CR16GBE00CT5 | 4 | 25 | 4 | 100 |
|
|
| CR16GBE00CU3 | 5 | 16 | 5 | 50 |
|
|
| CR16GBE00CV1 | 5 | 20 | 5 | 75 |
|
|
| CR16GBE00CW9 | 5 | 25 | 5 | 100 |
|
|
| CR16GBE00CX6 | 6 | 16 | 6 | 50 |
|
|
| CR16GBE00CY4 | 6 | 25 | 6 | 75 |
|
|
| CR16GBE00CZ2 | 6 | 30 | 6 | 100 |
|
|
| CR16GBE00D03 | 6 | 40 | 6 | 150 |
|
|
| CR16GBE00D11 | 8 | 20 | 8 | 60 |
|
|
| CR16GBE00D29 | 8 | 30 | 8 | 100 |
|
|
| CR16GBE00D37 | 8 | 50 | 8 | 150 |
|
|
| CR16GBE00D45 | 10 | 25 | 10 | 75 |
|
|
| CR16GBE00D52 | 10 | 40 | 10 | 100 |
|
|
| CR16GBE00D60 | 10 | 50 | 10 | 150 |
|
|
| CR16GBE00D78 | 12 | 25 | 12 | 75 |
|
|
| CR16GBE00D86 | 12 | 40 | 12 | 100 |
|
|
| CR16GBE00D94 | 12 | 50 | 12 | 150 |
|
|
| CR16GBE00DA6 | 16 | 40 | 16 | 100 |
|
|
| CR16GBE00DB4 | 16 | 50 | 16 | 150 |
|
