102-4-Flute GP-0X Solid Carbide Ball Nose-Metric-4.1-to-9.9mm

Description
  • 4-Flute Carbide End Mills Ball Nose comes with TiALN coating,
  • Economical Carbide Ball Nose End Mills to be used for softer materials up to 35-HRc,
  • Carbide Ball Nose End Mills to be used on MLTR, milling machine, VMC & HMC at lower parameters,
  • Ball Nose End Mills good for milling metals like MS, Cast Iron, GCI, Wood, Aluminum etc.

Item List

Item Special Treatment Flute Dia (mm) Flute Length (mm) Shank Dia (mm) Overall Length (mm)
CX01GBE001F5 TiAlN 5 16 5 50

CX01GBE001H1 TiAlN 5 25 5 75

CX01GBE001K4 TiAlN 5 35 5 100

CX01GBE001M0 TiAlN 6 18 6 50

CX01GBE001P3 TiAlN 6 30 6 75

CX01GBE001R9 TiAlN 6 35 6 100

CX01GBE001T4 TiAlN 6 40 6 150

CX01GBE001W8 TiAlN 8 20 8 60

CX01GBE00202 TiAlN 8 30 8 75

CX01GBE00210 TiAlN 8 40 8 100

CX01GBE00236 TiAlN 8 50 8 150

CX01GBE00BG6 TiAlN 8 30 8 200

CX01GBE00CH3 TiAlN 8 30 8 150

CX0XGBE00104 None 5 22 5 50

CX0XGBE00120 None 6 22 6 50
