M2-Jobber HSS Drill Bits-Metric

Description
  • Parallel Shank HSS Drill bits are manufactured from HSS AISI M2 grade,
  • Standard of HSS Drill bits followed is DIN 338 ,
  • These HSS Drills bits comes with Split Point and hardness of 62~65 HRc,
  • Every drill bit is tested thoroughly to pass stringent quality parameters at RIGPL

Item List

Item Flute Dia (mm) Flute Length (mm) Shank Dia (mm) Overall Length (mm)
HR1XGDR00JY2 1 12 1 34

HR1XGDR00JZ0 1.1 14 1.1 36

HR1XGDR00K01 1.2 16 1.2 38

HR1XGDR00K19 1.3 16 1.3 38

HR1XGDR00K27 1.4 18 1.4 40

HR1XGDR00K35 1.5 18 1.5 40

HR1XGDR00K50 1.7 20 1.7 43

HR1XGDR00K76 1.9 22 1.9 46

HR1XGDR00K84 2 24 2 49

HR1XGDR00K92 2.1 24 2.1 49

HR1XGDR00KB2 2.3 27 2.3 53

HR1XGDR00KC0 2.4 30 2.4 57

HR1XGDR00KD7 2.5 30 2.5 57

HR1XGDR00KE5 2.6 30 2.6 57

HR1XGDR00KF3 2.7 33 2.7 61

HR1XGDR00KG1 2.8 33 2.8 61

HR1XGDR00KH9 2.9 33 2.9 61

HR1XGDR00KJ4 3 33 3 61

HR1XGDR00KK2 3.1 36 3.1 65

HR1XGDR00KL0 3.2 36 3.2 65

HR1XGDR00KP1 3.5 39 3.5 70

HR1XGDR00KQ9 3.6 39 3.6 70

HR1XGDR00KR7 3.7 39 3.7 70

HR1XGDR00KS4 3.8 43 3.8 75

HR1XGDR00KT2 3.9 43 3.9 75

HR1XGDR00KV8 4.1 43 4.1 75

HR1XGDR00KW6 4.2 43 4.2 75

HR1XGDR00KX3 4.3 47 4.3 80

HR1XGDR00KY1 4.4 47 4.4 80

HR1XGDR00KZ9 4.5 47 4.5 80

HR1XGDR00L00 4.6 47 4.6 80

HR1XGDR00L18 4.7 47 4.7 80

HR1XGDR00L26 4.8 52 4.8 86

HR1XGDR00L34 4.9 52 4.9 86

HR1XGDR00L42 5 52 5 86

HR1XGDR00L59 5.1 52 5.1 86

HR1XGDR00L75 5.3 52 5.3 86

HR1XGDR00L83 5.4 57 5.4 93

HR1XGDR00L91 5.5 57 5.5 93

HR1XGDR00LA3 5.6 57 5.6 93

HR1XGDR00LB1 5.7 57 5.7 93

HR1XGDR00LC9 5.8 57 5.8 93

HR1XGDR00LD6 5.9 57 5.9 93

HR1XGDR00LF2 6.1 63 6.1 101

HR1XGDR00LG0 6.2 63 6.2 101

HR1XGDR00LH8 6.3 63 6.3 101

HR1XGDR00LJ3 6.4 63 6.4 101

HR1XGDR00LK1 6.5 63 6.5 101

HR1XGDR00LL9 6.6 63 6.6 101

HR1XGDR00LM7 6.7 63 6.7 101

HR1XGDR00LN4 6.8 69 6.8 109

HR1XGDR00LP0 6.9 69 6.9 109

HR1XGDR00LQ8 7 69 7 109

HR1XGDR00LR6 7.1 69 7.1 109

HR1XGDR00LS3 7.2 69 7.2 109

HR1XGDR00LT1 7.3 69 7.3 109

HR1XGDR00LU9 7.4 69 7.4 109

HR1XGDR00LV7 7.5 69 7.5 109

HR1XGDR00LW5 7.6 75 7.6 117

HR1XGDR00LX2 7.7 75 7.7 117

HR1XGDR00LY0 7.8 75 7.8 117

HR1XGDR00LZ8 7.9 75 7.9 117

HR1XGDR00M09 8 75 8 117

HR1XGDR00M17 8.1 75 8.1 117

HR1XGDR00M25 8.2 75 8.2 117

HR1XGDR00M33 8.3 75 8.3 117

HR1XGDR00M41 8.4 75 8.4 117

HR1XGDR00M58 8.5 75 8.5 117

HR1XGDR00M66 8.6 75 8.6 125

HR1XGDR00M74 8.7 81 8.7 125

HR1XGDR00M82 8.8 81 8.8 125

HR1XGDR00M90 8.9 81 8.9 125

HR1XGDR00MA2 9 81 9 125

HR1XGDR00MB0 9.1 81 9.1 125

HR1XGDR00MC8 9.2 81 9.2 125

HR1XGDR00MD5 9.3 81 9.3 125

HR1XGDR00ME3 9.4 81 9.4 125

HR1XGDR00MF1 9.5 81 9.5 125

HR1XGDR00MG9 9.6 81 9.6 125

HR1XGDR00MH7 9.7 81 9.7 133

HR1XGDR00MJ2 9.8 87 9.8 133

HR1XGDR00MK0 9.9 87 9.9 133

HR1XGDR00MM6 10.1 87 10.1 133

HR1XGDR00MP9 10.3 87 10.3 133

HR1XGDR00MQ7 10.4 87 10.4 133

HR1XGDR00MS2 10.6 87 10.6 133

HR1XGDR00MT0 10.7 94 10.7 142

HR1XGDR00MU8 10.8 94 10.8 142

HR1XGDR00MV6 10.9 94 10.9 142

HR1XGDR00MW4 11 94 11 142

HR1XGDR00MX1 11.1 94 11.1 142

HR1XGDR00MY9 11.2 94 11.2 142

HR1XGDR00MZ7 11.3 94 11.3 142

HR1XGDR00N08 11.4 94 11.4 142

HR1XGDR00N16 11.5 94 11.5 142

HR1XGDR00N24 11.6 94 11.6 142

HR1XGDR00N32 11.7 94 11.7 142

HR1XGDR00N40 11.8 94 11.8 142

HR1XGDR00N57 11.9 101 11.9 151

HR1XGDR00N65 12 101 12 151

HR1XGDR00N73 12.1 101 12.1 151

HR1XGDR00N99 12.3 101 12.3 151

HR1XGDR00NB9 12.5 101 12.5 151

HR1XGDR00NC7 12.6 101 12.6 151

HR1XGDR00ND4 12.7 101 12.7 151

HR1XGDR00NE2 12.8 101 12.8 151

HR1XGDR00NF0 12.9 101 12.9 151

HR1XGDR00NG8 13 101 13 151
